ASTM A269 S30403 / S31603 Stainless Steel Welded Tube Coiled Stainless Tubing

Chứng nhận
chất lượng tốt Ống thép Duplex giảm giá
chất lượng tốt Ống thép Duplex giảm giá
Pipes are really good . Good surface , good quality , also good delivery time . We trust the sales guy . Very patience .

—— Ugur - Turkey

Seamless coiled tubing is good . Regularly order is very worthful .

—— Gerardo Romero - America

Chúng tôi luôn mua ống được đánh bóng từ MTSCO, chất lượng thực sự tốt. Rất vui được hợp tác với MTSCO. Một đối tác tốt.

—— Paolo - Italy

Tôi trò chuyện trực tuyến bây giờ

ASTM A269 S30403 / S31603 Stainless Steel Welded Tube Coiled Stainless Tubing

Trung Quốc ASTM A269 S30403 / S31603 Stainless Steel Welded Tube Coiled Stainless Tubing nhà cung cấp
ASTM A269 S30403 / S31603 Stainless Steel Welded Tube Coiled Stainless Tubing nhà cung cấp ASTM A269 S30403 / S31603 Stainless Steel Welded Tube Coiled Stainless Tubing nhà cung cấp

Hình ảnh lớn :  ASTM A269 S30403 / S31603 Stainless Steel Welded Tube Coiled Stainless Tubing

Thông tin chi tiết sản phẩm:

Place of Origin: CHINA
Hàng hiệu: MTSCO
Chứng nhận: ISO 9001 & PED & AD2000
Model Number: MTSCOSSCT39

Thanh toán:

Minimum Order Quantity: negotiable
Giá bán: negotiable
Packaging Details: Iron Case / Plywood Case
Delivery Time: 30 Days
Payment Terms: T / T ; L / C
Supply Ability: 300 Tons / Month
Contact Now
Chi tiết sản phẩm
Material: S30403 / S31603 Standard: ASTM A269 / ASTM A213 Dual Standards Etc
Delivery Condition: Soft / Hard Type: welded
Surface: Bright Annealed / Pickled Feature: flame retardant

ASTM A269 S30403 / S31603 Stainless Steel Welded Coiled Tube For Multi-core Tube





Chemical Composition



  C(max) Si(max) Mn(max) P(max) S(max) Cr Ni Mo Ti
TP304/1.4301 0.080 1.00 2.00 0.045 0.030 18.0-20.0 8.0-10.5
TP304L/1.4307 0.035 1.00 2.00 0.045 0.030 18.0-20.0 8.0-12.0
TP316/1.4401 0.080 1.00 2.00 0.045 0.030 16.0-18.0 11.0-14.0 2.0-3.0
TP316L/1.4404 0.035 1.00 2.00 0.045 0.030 16.0-18.0 10.0-14.0 2.0-3.0



Where the multi-core coiled tubing used ?


     Mtsco’ s multi-core tubes are used for pneumatic and hydraulic remote control, measuring and monitoring systems. materials are ASTM TP316/ 316L, TP304/304L.

nditions.





Ordering code number

Tube size

(O.D x Thickness x Core)

Overall Diameter

(.mm)

Sheath Thickness

(.mm)

Bundle Weight

(kg/M)

Max Pressure

(Bar)

HTD-1 6×1.0×1 8 1.0 0.15

Working:180Bar



Test:270Bar

HTD-2 6×1.0×2 20 2.0 0.60
HTD-3 6×1.0×3 21 2.0 0.75
HTD-4 6×1.0×4 24 2.0 0.82
HTD-5 6×1.0×5 25 2.0 0.90
HTD-6 6×1.0×6 27 2.0 1.04
HTD-7 6×1.0×7 27 2.0 1.15
HTD-8 6×1.0×8 32 2.2 1.40
HTD-9 8×1.0×1 10 1.0 0.28
HTD-10 8×1.0×2 24 1.8 0.89
HTD-11 8×1.0×3 26 2.0 1.12
HTD-12 8×1.0×4 28 2.0 1.33
HTD-13 8×1.0×5 31 2.0 1.67
HTD-14 8×1.0×6 34 2.0 2.00
HTD-15 8×1.0×7 34 2.0 2.15
HTD-16 8×1.0×8 40 2.2 2.60
HTD-17 10×1.0×1 13 1.0 0.34
HTD-18 10×1.0×2 28 1.8 1.18
HTD-19 10×1.0×3 31 2.0 1.60
HTD-20 10×1.0×4 34 2.0 1.97
HTD-21 10×1.0×5 37 2.0 2.20
HTD-22 10×1.0×6 40 2.0 2.40
HTD-23 10×1.0×7 40 2.0 2.52
HTD-24 10×1.0×8 48 2.5 3.20
HTD-25 12×1.0×1 14 1.0 0.41
HTD-26 12×1.0×2 34 2.0 1.35
HTD-27 12×1.0×3 36 2.0 1.96
HTD-28 12×1.0×4 39 2.0 2.37
HTD-29 12×1.0×5 43 2.0 2.70
HTD-30 12×1.0×6 47 2.0 3.00
HTD-31 12×1.0×7 47 2.0 3.14
HTD-32 12×1.0×8 55 2.5 3.90



ASTM A269 S30403 / S31603 Stainless Steel Welded Tube Coiled Stainless Tubing




The multi-core tube consists of one to nine stainless steel tubes laid up spirally inside an extruded outer PVC sheath. For easy identification and protection purposes each individual tube is PVC sheathed in a different color. The extruded outer sheath is made of oil and seawater resistant, weatherproof, flame retardant, corrosion and acid resistant PVC. The multi-core tube (outer sheath) is continuously marked at every one meter throughout the entire length for easy installation. Heat shrinkable products provide complete water sealing, abrasion and corrosion protection under all conditions.
