Name: S30908 / S31008 Stainless Steel Hydraulic Tubing Size 9.53*8 BWG With Bright Annealed Surface
Brand: MTSCO
SKU: MTSCOHT25
Price: 4300 USD
Availability: InStock
ISBN: 9346675

Thông tin chi tiết
Material:	300 Series Stainless Steel	Surface:	Polished 400 # 320 # Etc
Type:	Seamless	NDT:	Eddy Current Or Hydraulic Test
Inspection:	100%	Technology:	Cold Drawn / Cold Rolled
Điểm nổi bật:	hydraulic pipe , Hydraulic Seamless Tube

Mô tả sản phẩm

S30908 / S31008 Stainless Steel Hydraulic Tubing Size 9.53*8 BWG With Bright Annealed Surface

Material Grade :

American Standard	TP304 , TP304L , TP310S , TP316 , TP316L , TP316Ti , TP321 , TP347 , 904L , S31803 Etc
European Standard	1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 , 1.4462 Etc
German Standard	X5CrNi18-10 , X2CrNi19-11 , X12CrNi25-21 , X5CrNi17-12-2 , X5CrNi17-12-3 , X2CrNiMo18-14-3 , X6CrNiTi18-10 , X6CrNiTb18-10 Etc

Applications :

1 . General service industries ( petroleum , food , chemical , paper , fertilizer , fabric , aviation and nuclear )

2 . Fluid , gas and oil transport

3 . Pressure and heat transmission

4 . Construction and ornament

5 . Boiler heat exchangers

6 . Decorative usage ( road lamp facilities , bridge handrail , expressway railing , bus stop , airport and gymnasium ) boiler , auto parts , medical equipment , building materials , food industry

Birmingham Wire Gauge BWG
	Wall Thickness			Wall Thickness
BWG	IN	MM	BWG	IN	MM
0	0.340	8.64	19	0.042	1.07
1	0.300	7.62	20	0.035	0.89
2	0.284	7.21	21	0.032	0.81
3	0.259	6.58	22	0.028	0.71
4	0.238	6.05	23	0.025	0.64
5	0.220	5.59	24	0.022	0.56
6	0.203	5.16	25	0.020	0.51
7	0.180	4.57	26	0.018	0.46
8	0.165	4.19	27	0.016	0.41
9	0.148	3.76	28	0.014	0.36
10	0.134	3.40	29	0.013	0.33
11	0.120	3.05	30	0.012	0.30
12	0.109	2.77	31	0.010	0.25
13	0.095	2.41	32	0.009	0.23
14	0.083	2.11	33	0.008	0.20
15	0.072	1.83	34	0.007	0.18
16	0.065	1.65	35	0.005	0.13
17	0.058	1.47	36	0.004	0.10
18	0.049	1.24

Specification :

DN	NPS(Inch)	D(mm)	SCH5S	SCH10S	SCH40S	STD	SCH40	SCH80	XS	SCH80S	SCH160	XXS
6	1/8	10.30	-	1.24	1.73	1.73	1.73	2.41	2.41	2.41	-	-
8	1/4	13.70	-	1.65	2.24	2.24	2.24	3.02	3.02	3.02	-	-
10	3/8	17.10	-	1.65	2.31	2.31	2.31	3.20	3.20	3.20	-	-
15	1/2	21.30	1.65	2.11	2.77	2.77	2.77	3.73	3.73	3.73	4.78	7.47
20	3/4	26.70	1.65	2.11	2.87	2.87	2.87	3.91	3.91	3.91	5.56	7.82
25	1	33.40	1.65	2.77	3.38	3.38	3.38	4.55	4.55	4.55	6.35	9.09
32	1 1/4	42.20	1.65	2.77	3.56	3.56	3.56	4.85	4.85	4.85	6.35	9.70
40	1 1/2	48.30	1.65	2.77	3.68	3.68	3.68	5.08	5.08	5.08	7.14	10.15
50	2	60.30	1.65	2.77	3.91	3.91	3.91	5.54	5.54	5.54	8.74	11.07
65	2 1/2	73.00	2.11	3.05	5.16	5.16	5.16	7.01	7.01	7.01	9.53	14.02
80	3	88.90	2.11	3.05	5.49	5.49	5.49	7.62	7.62	7.62	11.13	15.24
90	3 1/2	101.60	2.11	3.05	5.74	5.74	5.74	8.08	8.08	8.08	-	-
100	4	114.30	2.11	3.05	6.02	6.02	6.02	8.56	8.56	8.56	13.49	17.12
125	5	141.30	2.77	3.40	6.55	6.55	6.55	9.53	9.53	9.53	15.88	19.05
150	6	168.30	2.77	3.40	7.11	7.11	7.11	10.97	10.97	10.97	18.26	21.95
200	8	219.10	2.77	3.76	8.18	8.18	8.18	12.70	12.70	12.70	23.01	22.23
250	10	273.10	3.40	4.19	9.27	9.27	9.27	15.09	12.70	12.70	28.58	25.40

S30908 / S31008 Stainless Steel Hydraulic Tubing Size 9.53*8 BWG With Bright Annealed Surface 0

MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement .

Stainless steel seamless bright annealed tube’s final surface is polished and bright annealed . And the polished grade is includes 180 # , 320 # , 400 # , 600 # , 800 # . According to standard very strictly , tubes which produced by us always have correct OD and WT tolerance . At fluid industry , bright annealed hydraulic tubing has its own important position . Their useful life is higher than other tubing .

Từ khóa:

Thông tin chi tiết sản phẩm:
Place of Origin:	CHINA
Hàng hiệu:	MTSCO
Chứng nhận:	ISO 9001 & PED & AD2000
Model Number:	MTSCOHT25
Thanh toán:
Minimum Order Quantity:	negotiable
Giá bán:	4300-9800USD/TON
Packaging Details:	Iron Case / Plywood Case
Delivery Time:	30 Days
Payment Terms:	T / T ; L / C
Supply Ability:	300 Tons / Month
