ASTM A269 / ASME SA269 1.4404 Stainless Steel U Bend Heat Exchanger Tubing For Oil And Gas

Thông tin chi tiết sản phẩm:
Place of Origin: CHINA
Hàng hiệu: MTSCO
Chứng nhận: ISO 9001 & PED & AD2000
Model Number: MTSCOHET25
Thanh toán:
Minimum Order Quantity: negotiable
Giá bán: 3700-9000USD/TON
Packaging Details: Plywood Case / Iron Case / Bundles
Delivery Time: 30 Days
Payment Terms: T / T ; L / C
Supply Ability: 300 Tons / Month

Thông tin chi tiết

Material: 1.4404 Type: Seamless
Technology: Cold Rolled Condition: Soft / Hard
Surface: Pickling & Annealing Length: 6096mm
Điểm nổi bật:

heat transfer tube

,

heat exchanger pipe

Mô tả sản phẩm

ASTM A269 / ASME SA269 1.4404 Stainless Steel U Bend Heat Exchanger Tubing For Oil And Gas

Product Description

Outer Diameter3.18-101.6mm
Wall Thickness0.5-20mm
NPS1/8"-24"
Schedule5/5S,10/10S,20/20S,40/40S,80/80S,120/120S,160/160S
Material Grade304/304L/316/316L/321/309S/310S, etc
StandardASTM A269, ASTM A312, etc
Applicationused in Fluid and Gas Transport, Structure and Machining,etc
CertificatesISO9001:2008, PED, BV
Process MethodCold Drawn/ Cold Rolled
Surface FinishAnnealed/ Polished
PackageWoven bag for each piece, then packed in seaworthy wooden cases
Delivery Time20-60 Days after receiving the deposit (Normally according to the order quantity)
Price ItemFOB, CIF or as negotiation
PaymentT/T(30% in advance, 70% against the BL Copy) or as negotiation
Quality RequirementMill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Main MarketEurope, Middle East, Southeast Asia, South America, etc



ASTM A269 Chemical Composition :


Elements304L(wt%) S30403304(wt%) S30400316L (wt%) S31603316 (wt%) S31600
(C) Carbon, max0.0350.080.0350.08
(Mn) Manganese, max2222
(P) Phosphorus, max0.0450.0450.0450.045
(S) Sulfur, max0.030.030.030.03
(Si) Silicon, max1111
(Ni) Nickel8.0 - 12.08.0 - 11.010.0 - 14.010.0 - 14.0
(Cr) Chromium18.0 - 20.018.0 - 20.016.0 - 18.016.0 - 18.0
(Mo) MolybdenumN/AN/A2.0 - 3.02.0 - 3.0
(Fe) IronBal.Bal.Bal.Bal.
(Cu) CopperN/AN/AN/AN/A
(N) NitrogenN/AN/AN/AN/A



Process :
1 . We use Cold Drawn techonology to produce U bend tube
2 . U bend tubes produce will accordance to customer's drawings
3 . To avoid oxidation , inert gas (Argon) is passed through tubes ID at the required flow rate
4 . The radius is checked for its OD and wall thinning with the recommended specification
5 . We'll choose three different position or as customer's require to make sure tubes quality . We'll do physical properties and micro-structure test
6 . Visual inspection for waviness and cracks is done with Dye Penetrant Test
7 . Each tube is then hydro tested at the recommended pressure to check for leakage




MTSCO is a leading manufacturer who is specialized in seamless tubes , bright annealed tubes , seamless coiled tubing etc . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement .
Our heat exchanger tube with pickling and annealing surface is very popular in boilers and heat exchangers industry , water heater industry , air-conditioning industry etc . This kind of seamless tubes are have a very important position in our all products .
