310S ASTM A269 Ống liền mạch bằng thép không gỉ cho bộ trao đổi nhiệt
Thông tin chi tiết sản phẩm:
|
|
Place of Origin: | CHINA |
---|---|
Hàng hiệu: | MTSCO |
Chứng nhận: | ISO 9001 & PED & AD2000 |
Model Number: | MTSCOSSST31 |
Thanh toán:
|
|
Minimum Order Quantity: | negotiable |
Giá bán: | 4300-9800USD/TON |
Packaging Details: | Iron Case |
Delivery Time: | 30 Days |
Payment Terms: | T / T ; L / C |
Supply Ability: | 300 Tons / Month |
Thông tin chi tiết |
|||
Material: | Stainless Steel 300 Series | Standard: | EN 10216-5 ; ASTM A213 / SA213 ; ASTM A269 / SA269 Etc |
---|---|---|---|
Surface: | Annealing | NDT: | Eddy Current Or Hydraulic Test |
Type: | Seamless | Delivery Condition: | Soft / Hard |
Điểm nổi bật: | Stainless Steel Seamless Tubing,ss Seamless Tubing |
Mô tả sản phẩm
TP304L / 1.4306 Stainless Steel Seamless Tube With Bright Annealed Surface In Oil And Gas Industry
Item |
Description |
|
Basic Information |
Material Grade |
TP304 , TP304L , TP304H , TP316 , TP316L , TP316Ti , TP309S , TP310S , TP321 , TP321H , TP347 , TP347H , S31803 , S32750 , S32205 etc |
Outer Diameter |
3.18-101.6mm |
|
Wall Thickness |
0.5-20mm |
|
Length |
Normally fixed length 6m , can as per customer’s requirement |
|
Standard |
ASTM A213 ; ASTM A269 ; ASTM A312 ; ASTM A789 ; ASTM A790 ect . |
|
Process Method |
Cold Drawn or Cold Rolled |
Application
a) For fluid & gas transport
b) Structure & machining
c) Petrochemical
d) Environmental protection
e) Electricity
f) Instrument industry etc
Advantages
a) Superior surface finish
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Price Item: FOB , CFR , CIF or as negotiation
ASTM A213 / A213M Chemical Composition :
Elements | 304L(wt%) S30403 | 304(wt%) S30400 | 316L (wt%) S31603 | 316 (wt%) S31600 |
(C) Carbon, max | 0.035 | 0.08 | 0.035 | 0.08 |
(Mn) Manganese, max | 2 | 2 | 2 | 2 |
(P) Phosphorus, max | 0.045 | 0.045 | 0.045 | 0.045 |
(S) Sulfur, max | 0.03 | 0.03 | 0.03 | 0.03 |
(Si) Silicon, max | 1 | 1 | 1 | 1 |
(Ni) Nickel | 8.0 - 12.0 | 8.0 - 11.0 | 10.0 - 14.0 | 10.0 - 14.0 |
(Cr) Chromium | 18.0 - 20.0 | 18.0 - 20.0 | 16.0 - 18.0 | 16.0 - 18.0 |
(Mo) Molybdenum | N/A | N/A | 2.0 - 3.0 | 2.0 - 3.0 |
(Fe) Iron | Bal. | Bal. | Bal. | Bal. |
(Cu) Copper | N/A | N/A | N/A | N/A |
(N) Nitrogen | N/A | N/A | N/A | N/A |
Birmingham Wire Gauge BWG | |||||
Wall Thickness | Wall Thickness | ||||
BWG | IN | MM | BWG | IN | MM |
0 | 0.340 | 8.64 | 19 | 0.042 | 1.07 |
1 | 0.300 | 7.62 | 20 | 0.035 | 0.89 |
2 | 0.284 | 7.21 | 21 | 0.032 | 0.81 |
3 | 0.259 | 6.58 | 22 | 0.028 | 0.71 |
4 | 0.238 | 6.05 | 23 | 0.025 | 0.64 |
5 | 0.220 | 5.59 | 24 | 0.022 | 0.56 |
6 | 0.203 | 5.16 | 25 | 0.020 | 0.51 |
7 | 0.180 | 4.57 | 26 | 0.018 | 0.46 |
8 | 0.165 | 4.19 | 27 | 0.016 | 0.41 |
9 | 0.148 | 3.76 | 28 | 0.014 | 0.36 |
10 | 0.134 | 3.40 | 29 | 0.013 | 0.33 |
11 | 0.120 | 3.05 | 30 | 0.012 | 0.30 |
12 | 0.109 | 2.77 | 31 | 0.010 | 0.25 |
13 | 0.095 | 2.41 | 32 | 0.009 | 0.23 |
14 | 0.083 | 2.11 | 33 | 0.008 | 0.20 |
15 | 0.072 | 1.83 | 34 | 0.007 | 0.18 |
16 | 0.065 | 1.65 | 35 | 0.005 | 0.13 |
17 | 0.058 | 1.47 | 36 | 0.004 | 0.10 |
18 | 0.049 | 1.24 |
